- Size: 270 stere
- Place of Origin: Shandong China
- Brand Name: Mingwei
- Model Number: QTZ315 (TC7040)
- Weight: 32000.000 kg
Model:QTZ315 (TC7040) Loading capacity Performance | ||||||||||||||
JIB/BOOM | Fall | Max.Load | 20 | 25 | 30 | 35 | 40 | 45 | 50 | 55 | 60 | 65 | 70 | |
m | t | |||||||||||||
70 | 4 Falls | 16.7 | 16 | 15.75 | 12.44 | 10.11 | 8.44 | 7.19 | 6.22 | 5.44 | 4.81 | 4.18 | 3.83 | 3.44 |
2 Falls | 38.8 | 8 | 8.00 | 8.00 | 8.00 | 2.00 | 7.74 | 6.78 | 6.00 | 5.37 | 4.85 | 4.41 | 4.02 | |
65 | 4 Falls | 20.22 | 16 | 16 | 12.64 | 10.27 | 8.58 | 7.32 | 6.33 | 5.54 | 4.90 | 4.36 | 3.91 | |
2 Falls | 39.4 | 8 | 8.00 | 8.00 | 8.00 | 8.00 | 7.86 | 6.89 | 6.11 | 5.47 | 4.93 | 4.48 | ||
60 | 4 Falls | 20.5 | 16 | 16 | 12.84 | 10.44 | 8.73 | 7.44 | 6.44 | 5.64 | 4.99 | 4.44 | ||
2 Falls | 39.96 | 8 | 8.00 | 8.00 | 8.00 | 8.00 | 7.99 | 7.00 | 6.20 | 5.55 | 5.02 | |||
55 | 4 Falls | 20.79 | 16 | 16 | 13.04 | 10.61 | 8.87 | 7.57 | 6.55 | 5.74 | 5.08 | |||
2 Falls | 40.52 | 8 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 7.11 | 6.30 | 5.64 | ||||
50 | 4 Falls | 21.07 | 16 | 16 | 13.24 | 10.77 | 9.01 | 7.69 | 6.66 | 5.84 | ||||
2 Falls | 41.08 | 8 | 8.00 | 8.00 | 8.00 | 8.00 | 8.00 | 7.22 | 6.40 | |||||
Model:QTZ315 (TC7040) Hoisting Technical Performance | ||||||||
Hoisting Mechanism | Fall | α=2 | α=4 | |||||
Hoisting Speed | m/min | / | 0-30 | 0-60 | / | 0-15 | 0-30 | |
t | 8 | 4 | 16 | 8 | ||||
Slewing | Slewing Speed | r/min | 0-0.7 | |||||
Trolley Adjustable | Trolley Speed | m/min | 0-65 | |||||
Total Power | kw | 180 | ||||||
