Jib/ Boom Radius

3～17.5

20

25

28

31.8

32

35

38

Load Capacity

(t)

2Fall

3

2.98

2.67

2.41

4Fall

6

5.14

3.94

3.43

2.93

2.91

2.6

2.34

Jib/ Boom Radius

40

45

48

50

55

58

60

Load Capacity

(t)

2Fall

2.25

1.93

1.77

1.68

1.47

1.36

1.3

4Fall

2.18

1.86

1.7

1.61

1.4

1.29

1.23

Model:QTZ100 (TC6013)        Hoisting Technical Performance

Hoisting

Mechanism

Hoisting

Speed

Fall

/

α=2

α=4

Speed

m/min

8.5

40

80

4.25

20

40

Corresponding  Max

   Loadiing

t

3

3

1.5

6

6

3

  Power

wkw

24/24/5.4

Slewing Mechanism

  Slewing Speed

r/min

0.62

  Power

 kww

3.7×2

Trolleying

Mechanism

 Trolleying  Speed

m/min

48/24

   Power

k kw

3.3/2.2

Jacking Mechanism

     Jacking Speed

m/min

0.55

     Power

kw

7.5

Total  Power

kw

36.7
