Product Details
- Size: 270 stere
- Place of Origin: Shandong China
- Brand Name: Mingwei
- Model Number: D125
- Weight: 32000.000 kg
Model:D125 Loading capacity Performance | ||||||||||
JIB/ BOOM | Fall | Max.Load | 20 | 25 | 30 | 35 | 40 | 45 | 50 | |
m | t | |||||||||
60 | 4 Falls | 18 | 10 | 9.09 | 7.05 | 5.35 | 4.0 | 2.99 | 2.32 | 2 |
2 Falls | 31 | 5.0 | 5.0 | 5.0 | 5.0 | 7.75 | 6.58 | 5.72 | 5.50 | |
50 | 4 Falls | 18 | 10 | 11.78 | 9.12 | 7.14 | 5.51 | 4.22 | 3.26 | 2.65 |
2 Falls | 31 | 5.0 | 5.0 | 5.0 | 5.0 | 5.0 | 4.22 | 3.26 | 2.65 | |
Model:D125 Hoisting Technical Performance | |||||||
Hoisting Mechanism | Hoisting Speed | Fall | / | α=2 | α=4 | ||
Speed | m/min | 15 | 30 | 30 | 60 | ||
Corresponding Max Loadiing | T | 6 | 3 | 12 | 6 | ||
Power | kw | 37/37 | |||||
Slewing Mechanism | Slewing Speed | r/min | 0.7 | ||||
Power | kw | 2x5 | |||||
Trolleying Mechanism | Trolleying Speed | m/min | 1min 40s | ||||
Power | kw | 35 | |||||
Jacking Mechanism | Jacking Speed | m/min | 0.4 | ||||
Power | kw | 7.5 | |||||
Power Total | kw | 89.5 | |||||
- Size: 270 stere
- Place of Origin: Shandong China
- Brand Name: Mingwei
- Model Number: D125
- Weight: 32000.000 kg
